HDRF-1070-C | Benchtop/Desktop Shield Box

Benchtop RF Shield Box for Wireless Testing

Bench-top / Table-Top Shield Box. It is designed for WLAN , wireless device testing. It supports 802.11a, b, g, n, a, ax, be. It also supports Bluetooth, RFID, 3G and 5G Device testing.

Download Data Sheet

Let's Connect

Contact us for sales and pricing information.

Free Consultation

Add to Inquiry

Product Specifications

Internal Dimensions

Width: 393 MM, Height: 194 MM, Depth : 266 MM

External Dimensions

Width: 480 MM, Height: 250 MM, Depth : 330 MM

Weight

Net Weight: 11.60 KG, Gross Weight: 16.60 KG

Packaging Dimensions

Width: 21.00 Inch, Height: 14.50 Inch, Depth: 26.00 Inch

Features of HDRF-1070-C

Designed and developed for WLAN and wireless device testing.
Supports 802.11a/b/g/n/ac/ax/be devices.
Also suited to Bluetooth, RFID, 3G and 5G device testing.
Wide range of I/O connector options — giving installers flexibility when wiring power, control and RF connections into the unit.
Thick RF absorbing foam deadens standing waves and reflections — reducing reflected energy inside the chamber, which keeps readings more repeatable.
Higher Level Isolation up-to 12GHz for accurate performance — keeps external RF signals from interfering with the device under test.
Equipped with shielded power filters for power connection in the box while still blocking all wireless signals — keeps external wireless signals out of the enclosure while still delivering power in.
Rugged construction for long life. Bench-top / Table-Top Shield Box Design — built to hold up under repeated day-to-day use in a working test lab.
Customized Size to suit application specific requirements ,ideal for test platforms — letting the enclosure be sized to the device under test or the surrounding rack.

Industries We Serve

IoT Device Testing

Know More

Telecommunication

Know More

Industrial Automation

Know More

Automotive

Know More

Consumer Electronics

Know More

SCROLL

RF Isolation

Shielding Effectiveness

≥ 130 dB @ 20 MHz ~ 1 GHz
≥ 120 dB @ 3 GHz
≥ 120 dB @ 5 GHz
≥ 115 dB @ 6 GHz
≥ 110 dB @ 7 GHz
≥ 110 dB @ 8 GHz
≥100 db @ 12 GHz

The RF shield box exceeds minimum required isolation shielding performance across the tested frequency range, ensuring reliable and consistent RF testing performance.
